Aeroplane construction and operation; including notes on aeroplane design and aerodynamic calculation, materials, etc. A comprehensive illustrated manual of instruction for aeroplane constructors, aviators, aero-mechanics, flight officers and students. Adapted either for schools or home study (1918)
Rathbun, John B · Chicago : Stanton and Van Vliet Co. · leaf 82
s must be made.Owing to the fact that the temperature decreases as we ELEMENTARY AERODYNAMICS iO gain altitude, further corrections must be made in thetabular values, but as the changes are rather difficult tomake and are relatively small we will not take the matterup at this point. Air Pressure on… … Fig. 1. Air Flow About a Flat Normal Plate. Pressure Zone at Front andVacuous Turbulent Zone at Rear (H). Arrows Show Directionof Flow. as shown in Fig. 1 and passes all around the edges ofthe plate (P-R), the stream reuniting at a point (M) farin the rear. Assuming the air flow from left to right,…
Airplanes
