The American house-carpenter; a treatise upon architecture, cornices and mouldings, framing, doors, windows, and stairs. Together with the most important principles of practical geometry (1852)

Hatfield, R. G. (Robert Griffith), 1815-1879 · New York : J. Wiley · leaf 255

An illustration from The American house-carpenter; a treatise upon architecture, cornices and mouldings, framing, doors, windows, and stairs. Together with the most important principles of practical geometry, 1852, leaf 255
Fit: 288. r to e c on the top. This elucidates Fig. 276 ; at which the lines,h 9 and i 8, correspond lo h 9 and i 8 in this figure. … 389.— To find the bevil for the edge of the plank. Theplank, before the face-mould is applied, must be bevilled accord-ing to the angle which the top of the imaginary block, or prism,in the previous figures, makes with the face. This angle is de-termined in the following manner : draw w i, (Fig.…

Carpentry · Architecture
