American machinists' handbook and dictionary of shop terms : a reference book of machine shop and drawing room data, methods and definitions (1914)

Colvin, Fred H. (Fred Herbert), 1867-1965, Stanley, Frank A. (Frank Arthur), b. 1874 · New York : McGraw-Hill book company ; London : Hill · leaf 663

An illustration from American machinists' handbook and dictionary of shop terms : a reference book of machine shop and drawing room data, methods and definitions, 1914, leaf 663
ean shops. 634 SCREW MACHINE TOOLS Saw Bench, Universal — Bench on which lumber is brought to the saw for ripping, cross-cutting, dadoing, mitering, etc.Saw, Cold — For sawing metal. Circular saws are generally usedthough not always, band saws being occasionally employed.^ -X, Saw, Hack —… … SCREW MACHINE TOOLS Box Tool, Bushing — The cutters in thistool are placed with edges radial tothe stock and may be adjusted to turnthe required diameter by the screwsin the rear. The stock is supportedin a bushing and must therefore bevery true and accurate as to size. Box Tool, Finishing — The…

Machine-shop practice

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
