American telegraphy and encyclopedia of the telegraph; systems, apparatus, operation (1909)
Maver, William, jr. [from old catalog] · New York, Maver publishing company · leaf 355
2,02 AMERICAN TELEGRAPHY. ence of D2 as compared with Dj ; while the large circumference of d^ as compared withthat of the siuface at which it gears, by friction, with d, gives the latter a comparativelyrapid motion. When d^ is moved to the left so that it assumes the ];osition indicated inFig,… … WHEATSTONE RECEIVER, paratively slow motion to d; thereby reducing the resistance at the fans, and thus per-mitting a more rapid movement of the clock-work. THE WHEATSTONE RECEIVER. The Wheatstone automatic receiver, or ink recorder, is outlined in Fig. 228. Theelectrical portion of the receiver…
Telegraph
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
