American telegraphy and encyclopedia of the telegraph; systems, apparatus, operation (1909)
Maver, William, jr. [from old catalog] · New York, Maver publishing company · leaf 532
oves at this slot, namely, the pin 0, Figs. 325?^, etc. This pin isnormally in such a position that just before the star-wheel enters the slot the pin enters aspace between two teeth of the star-wheel, and puts those teeth in positive alignmentwith the grooves /, s, r. Inasmuch, however, as when… … 436/ AMERICAN TELEGRAPHY FIG. 32^fn. out of its normal position by the extension s (carried on a slide-bar) by means of thesmall chain and pulley, d i, Fig. 325//^, and^j, Fig. 3250, which are actuated each time the attendant manually pullsout the rod m {see Figs. 325/^,325^). When this rod…
