American text books of art education : Geometrical drawing (1873)
Smith, Walter, 1836-1886 · Boston : James R. Osgood & Co. · leaf 43
. Make D E equal to A. With D as centre, radius B. describe anare below D E and to the right of D. With E as centre, same radius,describe an arc above D E and to the left of E. From the same cen-tres, with radius C, cut the first arcs in F and G. Draw DFEG,the required rhomboid. Prob. 32.— On a…
Geometrical drawing
