The analysis & reproduction of textile fabrics : being a reasonable explanation of the necessary calculations and processes involved in analysing, effecting the required changes, and reproducing all the principal types of woven textures, from the raw materials to the finished cloth ; with an appendix upon "The cost of cloths." (1894)

Barker, A. F. (Aldred Farrer), b. 1868 · Manchester : Marsden · leaf 108

An illustration from The analysis & reproduction of textile fabrics : being a reasonable explanation of the necessary calculations and processes involved in analysing, effecting the required changes, and reproducing all the principal types of woven textures, from the raw materials to the finished cloth ; with an appendix upon "The cost of cloths.", 1894, leaf 108
Fig. 39. the remaining 16 hooks—8 on one edge of the machineand 8 on the other edge—will be taken to form the listor edge to the fabric on their respective sides. Design XXVIII. illustrates the production of stripedpatterns by the use of harness and shafts combined.Section a represents some figure…

Textile design · Weaving
