The analysis & reproduction of textile fabrics : being a reasonable explanation of the necessary calculations and processes involved in analysing, effecting the required changes, and reproducing all the principal types of woven textures, from the raw materials to the finished cloth ; with an appendix upon "The cost of cloths." (1894)

Barker, A. F. (Aldred Farrer), b. 1868 · Manchester : Marsden · leaf 123

An illustration from The analysis & reproduction of textile fabrics : being a reasonable explanation of the necessary calculations and processes involved in analysing, effecting the required changes, and reproducing all the principal types of woven textures, from the raw materials to the finished cloth ; with an appendix upon "The cost of cloths.", 1894, leaf 123
ped in the pattern by means of brackets on thethe design paper, as shown in Design XXX. andXXXI. 3. Obtain the full design by following each threadthroughout the repeat by means of the piece-glass. 4. Examine to see what reduction can be made inthe number of doups or ordinary shafts, should any… … FlG. 48. lively simple one. Take such an example as thatrepresented in Figure 48. Intricate it undoubtedly looks,but if the analyst for the moment throws aside all Ill consideration of the combination of ordinary figure andgauze, and carefully examines each as separate anddistinct patterns, and,…

Textile design · Weaving

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
