The analysis & reproduction of textile fabrics : being a reasonable explanation of the necessary calculations and processes involved in analysing, effecting the required changes, and reproducing all the principal types of woven textures, from the raw materials to the finished cloth ; with an appendix upon "The cost of cloths." (1894)

Barker, A. F. (Aldred Farrer), b. 1868 · Manchester : Marsden · leaf 130

An illustration from The analysis & reproduction of textile fabrics : being a reasonable explanation of the necessary calculations and processes involved in analysing, effecting the required changes, and reproducing all the principal types of woven textures, from the raw materials to the finished cloth ; with an appendix upon "The cost of cloths.", 1894, leaf 130
t elaborate figures may be designed onthis scheme of construction, which may nevertheless beanalysed with comparative ease according to the fore-going particulars. Extra Weft Figures upon Gauze Grounds. —Of the many methods of figuring with gauze in unisonwith other orders of interweaving none give… … Fig. 52. So far as analysis is concerned, the perusal of the fore-going particulars will render it very simple, the gauzestructure being first ascertained and put upon the designpaper, ruled to the required particulars, and then thefigure painted on by reference to the ground texture. For example:…

Textile design · Weaving

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
