span as indicated in figure 19 (a). The values of CJk are obtained from figure 16 for the wing plan form used. If the ailerons are differentially operated, then it may be better to divide the ordinates of figure 16 by 2 and to determine the value of the moment given by each aileron as indicated in… … (a) Ailerons deflected equally. (b) Ailerons deflected differentially. Figure 19.— Addition of effect of aileron elements. c, qcTfidy Front view Figure 20— Action of dihedral in producing yawing moment in sideslip. If the angle-o f-at tack change caused by deflecting (a) A = 6. the ailerons is…
