FIG. 309. FIG. 310. FIG. 311. Fig. 312 shows the section of a steam-cylinder by a plane passing throughits axis, with its piston and rod in full. To define its shadows, conceive thepiston P to be removed; the shadow cast into the interior of the cylinder willthen consist of that projected bjf the…
