372 MACHINE DESIGN AND MECHANICAL CONSTRUCTIONS. can be so nicely adjusted that the valve works freely and perfectly steam-tight.When the pressure is greater in the cylinder than in the chest, the pressure-plate is forced back, to the instant relief of the cylinder. Cylindrical Valves.—Fig. 845… … FIG. 845. chest S is central and incloses the valve ; the exhaust chambers E E are at theends of the valve, and are connected through the hollow stem or body of thevalve. The valve depends on its accuracy of fit for its tightness. The valve-chamber is bored out and ground, the valve is turned,…
