FIG. 165. FIG. 166. FIG. 167. carried to each angle, and to all the dots on the sides. As in the precedingfigure, slight curves are made on either ofthe side-lines, and the trefoil isadded to each angle, with the base of the middle leaf touching the transverseworking-lines between the sides.It will…
