A- i … Fig. 420. For common engines the cut-off is effected by the lap and lead of the valve (Fig.420), When the valve is placed centrally over the ports, the portion of the valve over-lapping the steam ports is known as lap; when on the steam side, it is designated asoutside lap, and as inside lap when…
