Worthen, William Ezra, 1819-1897, [from old catalog] ed · New York, Appleton · leaf 244
ched to the centre e and to the slider in the vibrating slotted link F, which ishung externally at its centre/; the link receives its motion from the eccentric rod Gattached to its lower end and connecting with the eccentric g. The sliding of the rod F in the slotted link by means of the levers,… … 228 MECHANICS. 7/ V/////////
Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
