Worthen, William Ezra, 1819-1897, [from old catalog] ed · New York, Appleton · leaf 254
/0^-<^-^^ Fig. 469. Beams, one end firmly fixed, the other supported, and loaded at the middle (Fig. 468).Safe load = 160 -y-. Beams with one end fixed, the other supported, and load uniformly distributed (Fig. 469). Id? Safe load = 240 MACHINE DESIGN AND MECHANICAL CONSTRUCTIONS. 237 Beams with… … Fig. 470. Fig. 471. Beams with both ends fixed, and load uniformly distributed (Fig. 471). Id?Safe load = 360 -y-. If the loads on a beam be neither at the centre nor uniformly distributed,but at intermediate points, it is important to determine the load which placedat the centre will produce an…
Mechanical drawing
