Worthen, William Ezra, 1819-1897, [from old catalog] ed · New York, Appleton · leaf 32
Fig. 45. Fig. 46. 2d Method (Fig. 47).—Draw a base line, as before, equal to A B. At oneextremity construct an angle equal to C A B, and at the other an angle equalto 0 B A. The sides of these angles will intersect, and form the requiredtriangle. Sd Method (Fig. 48).—Construct an angle of the…
Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
