Fig. 738. Fig. 739. Fig. 740. Fig. 741. ing. Figs. 738, 739, and 741 are sockets for wire-rope connections, shown insection. Fig 739, with a wrought-iron conical key; often the wires of the ropeare spread with wrought-iron wedges or nails, and in addition lead is poured in. MACHINE DESIGN AND…
