Worthen, William Ezra, 1819-1897, [from old catalog] ed · New York, Appleton · leaf 364
ns of the bar as aunit, and adapted to usual work. Ifthere is much motion at the joint, thewearing-surface should be larger, byincreasing the wddth of the eyes andthe length of the pin. The pin in thedrawing is through the collar; usually the pin is extended, and the pin passesthrough the bolt… … us MACHINE DESIGN AND MECHANICAL CONSTRUCTIONS. Fig. 777 is the side elevation of the eccentric and strap of a Reynolds20^ X 48^ Corliss engine. The eccentric rod is made with a shoulder, the stemis fitted to the l^^* socket, and held firmly by a nut in the 4 groove. Fig. 778 is a double eccentric,…
Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
