Worthen, William Ezra, 1819-1897, [from old catalog] ed · New York, Appleton · leaf 506
Fig. 116.3. Fig. 1164. represents the elevation and plan of a cast-iron king-head for a roof similar toFig. 1151 ; Fig. 1161, that of the brace-shoe ; Fig. 1162, that of the rafter-shoe ENGINEERING DRAWING. 489 … Fig. 1165. for the same roof; Fig. 11G3, the front and side elevation of the queen-headof roof similar to Fig. 1152 ; and Fig. 1104, elevation and plan of queen brace-shoe. Fig. 1165 represents the section of a rafter-shoefor a tie-rod ; the side flanges are shown in dotted line. On the size and…
Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
