ENGINEERING DRAWING. 513 Figs. 1224 to 1228 are illustrations of a landing-bridge common at NewYork city ferries. Fig. 1224 is a longitudinal section, showing a section of the float,/, with its lever shown at oneside of the float and stone coun-terpoise to balance the weight of thebridge. Fig. 1225…
