e, while the plate framemay be called the English practice. The latter admits of a wider fire-box be-tween the frames, but in the American example the fire-box is entirely abovethe frames. TheWave-line Princi/ple of Ship-Co?istruction, from B^usselVs Naval Archi- k. Draw-bar. I, Journal-box. m,… … Fig. 1302. tecture.—The general doctrines arrived at by J. Scott Russell, F. R. S., fromnumerous and long-continued experiments and practical tests, is that theform of least resistance for the water-line of the bow is horizontally the curveof versed sines, and that the form of least resistance for…
