FiG. 1627. Fig. 1628. plied at the angles only, so that it might be supported by four flying buttresses,placed in the direction of the resultants, and strong enough to resist thepressure. Fig. 1629 represents a compartment of the simplest Gothic vaulting—a, «,groin ribs; Z*, J, ^, side ribs. The…
