Worthen, William Ezra, 1819-1897, [from old catalog] ed · New York, Appleton · leaf 693
es is, that while theupper ends of the English loops or leaves are round, or simply pointed, theupper ends of the latter terminate, like their lower ones, in angles of contact,giving a flamelike form to the tracery bars and form pieces. 676 ARCHITECTURAL CONSTRUCTION. In England the Perpendicular… … FiG. 1663. Fig. 1664. Fig. 1665. cipal lights, and thus the upper portion of the window is filled with panel-likecompartments. The principal as well as the subordinate lights are foliated intheir heads, and large windows are often divided horizontally by transoms.The forms of the window arches vary…
Mechanical drawing
