Worthen, William Ezra, 1819-1897, [from old catalog] ed · New York, Appleton · leaf 751
FiG. 1815. 734 FREE-HAND DRAWING. … Fig. 1816. vided into seven equal parts. The upper division is from the top of the headto the shoulders. Let C D be the axis of the figure, the line at the breadth ofthe shoulders is f of the whole height A B. The point E is the centre of the FREE-HAND DRAWING. 735 line C D ; draw through this…
Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
