Worthen, William Ezra, 1819-1897, [from old catalog] ed · New York, Appleton · leaf 752
Fig. 1817. the line of the knee-pan is on i h. The length of the foot is -| of a division, A1.Having established these proportions, it will be seen by the following cuts howthe artisan gave movements to these figures when the movements were not inabsolute profile. Suppose the weight of the figure…
Mechanical drawing
