Worthen, William Ezra, 1819-1897, [from old catalog] ed · New York, Appleton · leaf 921
The Stirling Boiler consists of three upper steam-drums and a lower mud-drum. Allthe steam-drums are connected at the top, but the front and middle drums only are con-nected in the water space. Tubes, 3^ diameter; movement of flame shown by arrowsaround baffle plates. 868 SCRAPS. … The Adendroth and Root Boiler was the earliest of its type on the market, and hasbeen modified in its details since its introduction to meet necessities which were devel-oped by use. The section gives the latest form. The angles of the tubes, with the hori-zontal and the bafl^le plates beneath and…
Mechanical drawing
