Earth Portion of the Neio Croton Dam, showing RubUe Masonnj Core. … Sweetwater Arched Masonry Dam, Southern California. The dimensions of this dam are : Thickness at base, 46 ft.; thickness at top, 12 ft.;height, 90 ft.; radius of arch at top, 222 ft. The upper face batter is 1 to 6 to within6 ft. of the top, thence vertical; on the lower face it is 1 to 3 for 28…
