Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 147
Scale.—3-28th inch = 1 foot. Horizontal Section through Tubes of Wing Boilers and Fujuaces of Centre Boiler. Scale.—3-2Sth inch = 1 toofcTransverse Section. BOILERS. 145 Figs. 4S3, 4S4, and 485, are different views of the boilers of the steamer Forth, belonging tothe English Mail Steam-Packet…
Mechanical engineering · Mechanics · Engineering
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
