their flooring, the triangles and frames which contain them. Fig. 997, the general plan of the second system, with disposition altogether similar to the first. The 334 CORN-MILLS. horizontal sections are here represented at different depths underneath the frame-work of the stones,exhibiting the… … figs. 098 and 999, a vertical section and plan of the iron axle of a mill-stone. Fi°s. 1000 and 1001, a vertical section and plan of the superior portion of one of the cast-iron pedes Fig. 1002, a steel socket on which the iron axle of the mill turns. tals. CORN-MILLS. 335
