Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 343
wheel into C... 1st pair of small bevels*2d do. do.... Diameter of the millstones, 4 feet. Literal References to Fig. 1004. A, the great bevel-wheel on the crank-shaft of first engine. B, the pinion on the mill-shaft working into the above. 0, a spur cog-pinion on the mill-shaft driven by the spur… … srr—- - ■ CORN-SHELLER. 341 a a a, the bevel wheels and pinions for driving the mill-spindles.6, a strong bracket for strengthening the bearing of the pinion B.c c, two cast-iron cross-stays for the same purpose.ddd, the feeding hoppers.eee, the frames supporting the feeding hoppers.///, the…
Mechanical engineering · Mechanics · Engineering
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
