carrying the dust, itc, outside of the mill.P, passage of the cleaned wheat to the second elevator.t /, the upright shaft for driving the light machinery of the mill.i, a pair of bevels between the upright shaft andk; the range of longitudinal shafting down the mill.Imnopqrs, pulleys for driving… … CORN-SHELLER. Fig. 1005 is a perspective view of L. M. Whitmans corn-sheller. A is the frame,B is a concave bed made of cast-iron plates, with projections on their inside surfaces. D is a cast-ironcylinder having projections cast on its outside surface. The ears of corn are fed in between the…
