rs, and flat tools orchisels. Of each of these four kinds there are various sizes. Fig. 1572 shows the form of a graver thatis principally used for outlining or separating one figure from another. A is the back of the tool; 13the face; C the point; and D what is technically calledthe belly. The… … D * A sharp-edured scraper, in shape something like a copper-plate engravers burnisher, is used in the process of loicerivg.t The handle, when received from the turners, is perfectly circular at the rounded end; but after the blade is inserted,n segment is cut off at the lower part, as seen in Fig.…
