re cut into female screws. The pair of geers are driven by one pinion N placed at the bottom of theupright shaft 0, on the top of which is a bevel eeer P, driven by another pinion Q placed on a hori-zontal shaft driven by pulleys R and leather bands or belts S S, three inches wide. There are two… … GAUGES. 737 bv the shaft T cam-inn; the pulleys U. This shaft is driven by a water wheel of fifty horse power, h?which means the whole of the gates can be lifted at one time, under almost any circumstances, in fif-teen minutes. GAUGE or GAGE, A measure of capacity or pressure. Of steam gages to…
