es in an inclined direction athwartthe whole depth of the water in t, and subdivides (as it were) the compartment t3 into two divisions.R R, R R, are a series of pairs of rollers, mounted transversely over the after part of the compartmentt3, at such an elevation that the under rollers revolve… … The action of this machinery, so far as it has been thus described, is as follows:The feeding-rollers G1 G2 G3 G4, the carrying-rollers of the endless webs H3 H3 and H4, and the rollersR R. are all made to revolve in a forward direction, or from left to right of the machine, as representedin Fig.…
