ank or first mover communicates motion to the drum, which inits turn transfers a rapid motion to the cutting-wheel, while a band which passes from a small pulley onthe drum-shaft, puts in operation a feeding screw-pulley, which moves the sliding-carriage horizontallyfrom left to right. Another… … During the revolution the pattern, bemg irregular in its surface, causes tlie axis to approach and re-cede from the wheel. Thus, it wdl be seen, as it presents its whole surface to the friction-wheel, so inlike manner the block presents its surface to the cutting-wheel, which feeing in rapid…
