, showing the geer-ing by which the tables that carry the spindles are made to revolve. 14 MEDDLES. A is the heddle-beam. BBBB are revolving spool-frames or tables. C represents the spool-spin-dles, a are slots in the spool-tables. Each table has six slots or spindle recesses, but only three… … fellow-table, as seen in Fig. 2253. The tables B B constitute one pair, and the tables B 2, B 3, another,forming two distinct harness, one on each side on two beams, but driven by the same geering. Thevarn is put on the spindles C, and passes through a hole in the top of the flyers D, or over a…
