Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)

D. Appleton and Company · New York : D. Appleton and Co. · leaf 201

An illustration from Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes, 1873, leaf 201 — 6, the driving cone-pulleys, loose on the spindle of the lathe and fast with the pinion p, Fig. 253S.h, a spur-wheel, fast on the back shaft, and i a pinion also fastened on the same. «•, a wheel fast onthe lathe-spindle, geering with the pinion i. c, is the chuck or face-plate ; this admits of… … Figs. 2541 and 2640, are end and side elevations of the shifting-head of which Fig. 2539 is a plaais a screw for shifting the spindle. A hand-wheel is placed on the outer end of it, which revolves in LATHE. 197

Mechanical engineering · Mechanics · Engineering

Internet Archive · Public Domain Mark 1.0. Free to use for anything.
