Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 213
Supposing de also to represent the stroke of the piston, and that the piston is on the top stroke, thenb d and bf are the respective positions of the crank and eccentric; for the slide, instead of occupyingits central position, when the piston is at the end of its stroke, (as in Case 1,) must be…
Mechanical engineering · Mechanics · Engineering
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
