he driving-pulley can beattafbed to the central shaft above the central pinion, Fig. 2264. The arbor of the planet-wheel isoiled through a hole in the wheel wliich delivers it at the junction of the sleeve and arbor; and in likemanner the central shaft and the sleeve tliat turns on the central… … Arrniigta to carry the belt from the hori2ontal pulley luider the foot-path on which the horse walks. The whole apparatus is made light and portable, rests on the case-frame, and turns on the centralstandard, which makes part of the base-frame, without supports or bearings at tlie top. The whole…
