Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 278
Fig. 2632, a transverse section of the diiving-wheel axle-bos, and of part of the outer spring ?ig2633, a longitudinal section of the same. Fig. 2634, a section of the suspending link for adjusting the weight of the engine on the springs • Fig2635, a side elevation of the same. 2609. 2610. 2611. … Fig. 2636, a general elevation of the tender brake-geer; Fig. 2637, a plan of the brake-lever andoothed sector; Fig. 2638, the screw and link-nut for the tender brake. Description of the engine.—The fire-box.—The first part of the engine which claims our attention isthe fire-box. The form of…
Mechanical engineering · Mechanics · Engineering
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
