ing shuttle. G, lever for taking up the cloth by operating on the ratchet-wheel H. This lever is worked by a«rank-motion attached to the end of cam-shaft. H, ratchet-wheel, operated by lever G. I, emery-roll; J, binder-roll; K, cloth-roll. The cloth, after passing between the rolls I and J, w… … LOOM, POWER. 0, lever, operated by cam, on cam-shaft. P, lever attached to 0, which comes in contact with catch L, (when the filling breaks,) and .brows tli»jhipper-handle Q out of the notch in which it is held, and stops the loom.Q, shipper-handle for stopping and starting the loom.
