liatever it may be, is in a correct position, the spindle K of the augur iaset in motion, and the operator gently brings down the weiglited lever 11, cutting out the rectangularmortise. There is but little work for the outside chisel of the augur to perform. The lever rests on the top of the… … MORTISING MACHINE. Figs. 2847 and 2848 represent a machine manufactm-ed by W. R. A\. Inslee, Newark, N. J., and from the simplicity of its plan it is much less liable to get out of orderthan others of a more complicate character. The action of the machine is suiBciently obvious. MOTION, in…
