. do. ilo. S, Eduction-valve, 26 do. do. tlo 9, Equilibrium steam-pipe.The induction and equilibrium nozzles are each connected to a separate port cast in tlie cylinders bot-tom. The eduction nozzle is connected by a pipe M, 34 inches cliameter, to the branch-pipe M of thecondenser. The pipe M is… … 7Ae hand-rjecr is connected to the weigh-post K, and the plug-rod is worked by a lever and shaft T,the outer end of which is slotted and worked by a pin on the sliding-ring e. Pumps.-—-The engine works eleven pumps of 63 inches diameter; each pump is furnished with acast-iron balance-beam H, (Fig.…
