view A B C D E are five pillars fixed to the sole-piece 1111, which support the strong eccentric casiog H H H H, and the top jomnal of the shaft F. G G is a cylinder keyed on the shaft F, and driven 628 SHINGLER, BLRDEXS PATENT. … SHOT, SMITHS PATENT. G29 in tlie direction of the arrow by the pinion I. K K is a heavy ring or thimble which is allowed to viseand tall up and down the shaft F; its weiglit upsets tlie upp?r end of the bloom. The dotted line atL represents a large hook, to deliver the bloom when finished. The…
