heel K, on the spindle of which is a small pinion which geers with a rack on the back of thebracket B B. The bracket is secured, when raised to its proper position, by the pinching-screw m, onthe outer end of wliieh a handle is fixed. C C is the sole of the radial arm D D. It is supported in… … E is the pulley-cone by which motion is communicated to the machine. On the spindle of this coueis keyed tlie bevel-wheel f, which geers with the similar wheel marked e on the vertical spindle p. Thisspindle is provided witli a sunk-feather to allow it to slide through the eye of the wheel ( when…
