required hyperbolic sine of thecomplex angle x -{-jy radians. In the case presented in Fig. 28, sinh(l +/1) = 0635+/1-2985 = 1-446/63-950. As x varies, Z moves along thehyperbola Zbz. As y varies Z moves along the ellipse XE#y.Both the ellipse and the hyperbola have foci at F and /, pointssituated… … FIG. 28.—Graphical Constructions for Sinh (a; ± jy) and Sinh-i (x ± jy}. Construction for Cosh (x -{-jy). Fig. 29.—Take OA = 1 alongthe positive end of the axis of reals. From OA as initial line, mark off the circular angle y, or the sector area AOB = ^. TO ELECTRICAL ENGINEERING PROBLEMS 61 From…
