Duncan, J. (John), d. 1941 · London, MacMillan and co., limited · leaf 282
FIG. 281.—Normal and shearing stresses. These equations require further examination. Both (i) and (2)refer to sections taken perpendicular to the paper, and give themaximum shearing stresses for such sections. Fig. 282 (a) shows abar under axial pull stress pl and transverse pull stress /2,…
Mechanics
