FIG. 546. — Forces in a loaded Porter governor, including effects due to the arms. Mw2R. The mass of the load is L, and half its weight, viz.will be borne by the right-hand arms as shown. The forces at A arebalanced direct by the reactions of the -pin securing AB to thespindle at A. The force J/ at…
