le the dehumidification cycle is tak-ing place in Unit No. 1, Unit No. 2 is beingreactivated. Air from outside is drawnthrough a gas flame in furnace E by the re-activating fan F. The mixture of air andproducts of combustion leaves the furnaceat a temperature of 300 deg. F., and entersthe gel beds.… … FIGURE IV THE ARCHITECT AND ENGINEER ^ 63 ► OCTOBER. NINETEEN THIRTY-TWO 150 deg. F.. When the gel has been thor-oughly dried the furnace burner is turnedoff and dampers change the air flow, sothat air is circulated from the beds throughcooler H and back to the gel bed over andover again. The water…
